This makes Control 23-1L an excellent choice for a wide variety of applications, including retail stores, restaurants, health clubs, theme parks, educational facilities, hospitality, music cafes, leisure venues, and anywhere where a top quality compact indoor/outdoor foreground/background music (and/or paging) speaker is required. The speaker provides a very natural sound character. The system is capable of handling 50 Watts continuous pink noise (100 Watts program). The combination of high sensitivity and power handling provides high Max SPL of 103 dB.
Features
- 3” woofer with woven fiberglass cone
- 1/2” PEI diaphragm tweeter with fluid cooling
- Contemporary, high-design appearance
- Built-in InvisiBall® mounting hardware, plus available U-bracket
- Weather resistant enclosure and transducers
- Wide 100° x 100° coverage
- 50 Watt power handling (100 Watt program)
- High fidelity sound character with broad frequency response of 70 Hz – 20 kHz
Generelt
- Model serie
- Control 20
- Applikation
- On wall
- Aktiv/Passiv
- Passive
- Farve
- Hvit
Højttalerenheder
- LF
- 3 "
- HF
- 0,5 "
Lydspecifikation
- Impedance
- 8 Ohm
- Frequency range Min
- 70 Hz
- Frequency range Max
- 20.000 Hz
- Følsomhed (1W/1m)
- 86 dB
- Strømhåndtering
- 40 W
- 70/100V
- Nej
- Max SPL
- 103 dB 109 peak
- Coverage angle (Hor)
- 100 °
- Coverage angle (Ver)
- 100 °
Dimensioner og vægt
- Bredde
- 141 mm
- Dybde
- 111 mm
- Højde
- 200 mm
- Nettovægt
- 1,6 kg
Yderligere oplysninger
- Udendørs brug
- Ja IP-44; IP-55 with optional WeatherMax grille/panel cover
- Inkluderet tilbehør
- InvisiBall wall-mounting system; 4 mm x 80 mm hex key
Forpakningsinfo
- Forpaknings størrelse
- 190 x 170 x 270 mm
- Forpaknings vægt
- 1,59 kg
Forpakningsinfo (2 pcs)
- Forpaknings størrelse
- 380 x 170 x 270 mm
- Forpaknings vægt
- 3,18 kg
