NDI HX3 Low Latency, High Quality Video Distribution
With NDI HX, video is transmitted over local area networks. Sources can be ingested into live production, AV and streaming platforms.
Encode HDMI to IP
Encoding HDMI sources to IP allows the use of affordable and centrally managed network switches and long-distance cabling. IP video can be securely streamed locally and globally.
USB and DisplayPort Conversion
OIP-N40E's USB port can convert USB (UVC/UAC) and DP signals for transmission over IP. It supports USB output (webcam extension) when used with OIP-N60D.
Camera Converter
OIP-N40E converts any HDMI camera into an IP device. Locally, a tally light indicates that the camera is live, while the IP signal is transmitted to decoders, computers or streaming platforms. OIP-N40E features a pass thru HDMI output.
Generelt
- Model serie
- Lumens AVOIP
- Extender type
- Transmitter (Tx)
- Teknologi
- NDI | HX, RTSP
Billedspecifikation
- Max understøttet opløsning
- 1920x1080
- Opdateringshastighed
- 60 Hz
Yderligere oplysninger
- Video ind
- HDMI
- Video ud
- HDMI, IP stream (RJ-45)
- Audio indgange
- 3,5mm jack
- Audio Udgange
- 3,5mm tele
- USB passthrough
- Ja
Forpakningsinfo
- Forpaknings størrelse
- 181 x 197 x 45 mm
- Forpaknings vægt
- 561 g
